Setting: Use free terminal assignment – No (default)

The digital inputs/digital outputs are assigned in the configuration of the software module in the Inputs/outputs menu. All inputs/outputs set to "Data Flexibility input" and that can be edited, can be freely assigned. All other inputs are already used and automatically assigned according to the settings of the Module configuration.

WARNING

Unexpected system behavior in the event of interrupted communication with the higher-level controller.

Death, severe injuries or damage to property.

• Make sure that the digital outputs control only those parts of the system that cannot give rise to hazardous situations.

• Assignment of digital inputs
• Assignment of digital outputs
• Configuring digital inputs/digital outputs
• Using additional I/O option cards
