Jerk time

WARNING

Unexpected system behavior by changing the jerk time during deceleration. If the jerk is reduced (increase jerk time) during deceleration, the target position might be overrun.

Death, severe injuries or damage to property.

• Change the jerk or jerk time only when the machine is at a standstill.

For the states listed below, the preset jerk time has no effect. In these cases, the "Jerk time" of the inverter configured under "Application limits" in the Limit values submenu of the "Monitoring functions" configuration menu is effective.

• When the operating mode "Stop at application limit" (FCB 13) is selected
• When the “Output stage enable/reset” signal is removed (FCB 01)
• When a fault response is active (FCB 13 or FCB 14)
