Opening the MOVIKIT® fieldbus monitor

Carry out the following steps to open the MOVIKIT® fieldbus monitor:

WARNING

Unexpected system behavior if the communication between the engineering PC and the MOVI‑C® CONTROLLER is interrupted (e.g. due to disconnection of the Ethernet cable) because the specified setpoints continue to take effect (for up to 30 s) until the connection to the IEC Editor is interrupted automatically and the IEC Editor is logged off.
May result in death, severe injuries or damage to property
  • In control mode, make sure that the drive can be stopped at any time by means of emergency off measures.
  1. In the MOVISUITE® project, open the context menu of the MOVI-C® CONTROLLER and select [IEC Editor] from the "Tools" submenu.
    • The IEC Editor opens.
  2. Open the [Online] menu and click [Login].
  3. In the device tree, double-click the "MOVIKIT_FieldbusMonitor" node. (Path: Default > PLC Logic > Application [run] > FieldbusMonitor)
  • The MOVIKIT® fieldbus monitor is opened in a new tab.
