Energy storage discharge (StorageDischarger)
The energy storage discharge operating mode (StorageDischarger) is used to discharge the DC link using a braking resistor connected to a MDP92A power supply module. The function block defines a maximum discharging capacity so that the specification of the connected braking resistor is not exceeded.
WARNING
Electric shock from a DC link capacity or energy storage unit that has not been fully discharged.
Severe or fatal injuries.
- Check whether there is any residual voltage and, if necessary, completely discharge the DC link capacity or the energy storage unit as described in the relevant documentation.
- Observe the safety notes and the documentation of the energy storage unit in use.
INFORMATION
To activate the operating mode, you must specify a value for the braking resistor and its continuous power in the configuration menu energy storage discharge.
